HGTR KTP Q-Switch

HGTR KTP has high resistivity and high damage threshold. It is suitable for making

 electro-optic devices with excellent properties and achievable price.

Typical Applications:

1. Q-switching.

2. E-O modulator.

3. Pulse picking.

Advantages:

1. Not hygroscopic and no need for protective windows.

2. Low half-wave voltage.

3. Low insertion loss.

4. Wide optical bandwidth.

5. High laser induced damage threshold.

6. No piezoelectric ringing allow to use in high repetition rate laser.

7. Thermally birefringence compensated design to operate in a large temperature range (-20℃-70℃).
